Viewing head | sliding binocular(30°) |
Nosepiece | quadruple |
Eyepiece | WF10X,P16X |
Achromatic objective | 4X,10X,40X,100X |
Stage | double layer mechanical stage140x140mm |
Focusing | coaxial coarse & fine adjustment,Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm |
Condenser | abbe condenser NA 1.20 with iris diaphragm & filter |
Illumination | halogen lamp 110V/220V,6V20W brightness adjustable. plain-concave mirror |
Packing | 1SETS/CTN |
Carton size | 33x28x44cm |
